Traffic Analysis for 11 -- raphael (Double Chooz)
System: | Primary electronics building switch in |
Maintainer: | sysadmin@nevis.columbia.edu |
Description: | 11 |
ifType: | ethernetCsmacd (6) |
ifName: | 11 |
Max Speed: | 1250.0 kBytes/s |
The statistics were last updated Tuesday, 7 August 2018 at 18:22,
at which time 'HP ProCurve Switch 2512' had been up for 155 days, 6:02:48.
`Daily' Graph (5 Minute Average)
|
Max |
Average |
Current |
In |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
Out |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
`Weekly' Graph (30 Minute Average)
|
Max |
Average |
Current |
In |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
Out |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
`Monthly' Graph (2 Hour Average)
|
Max |
Average |
Current |
In |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
Out |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
0.0 B/s (0.0%) |
`Yearly' Graph (1 Day Average)
|
Max |
Average |
Current |
In |
4579.0 B/s (0.4%) |
421.0 B/s (0.0%) |
0.0 B/s (0.0%) |
Out |
39.5 kB/s (3.2%) |
5336.0 B/s (0.4%) |
0.0 B/s (0.0%) |
GREEN ### |
Incoming Traffic in Bytes per Second |
BLUE ### |
Outgoing Traffic in Bytes per Second |
