Traffic Analysis for 8 -- leonardo (Double Chooz)
System: | Primary electronics building switch in |
Maintainer: | sysadmin@nevis.columbia.edu |
Description: | 8 |
ifType: | ethernetCsmacd (6) |
ifName: | 8 |
Max Speed: | 1250.0 kBytes/s |
The statistics were last updated Tuesday, 7 August 2018 at 18:22,
at which time 'HP ProCurve Switch 2512' had been up for 155 days, 6:02:48.
`Daily' Graph (5 Minute Average)
|
Max |
Average |
Current |
In |
5.0 B/s (0.0%) |
1.0 B/s (0.0%) |
1.0 B/s (0.0%) |
Out |
1536.0 B/s (0.1%) |
1025.0 B/s (0.1%) |
1164.0 B/s (0.1%) |
`Weekly' Graph (30 Minute Average)
|
Max |
Average |
Current |
In |
21.0 B/s (0.0%) |
1.0 B/s (0.0%) |
1.0 B/s (0.0%) |
Out |
1602.0 B/s (0.1%) |
766.0 B/s (0.1%) |
1177.0 B/s (0.1%) |
`Monthly' Graph (2 Hour Average)
|
Max |
Average |
Current |
In |
534.0 B/s (0.0%) |
4.0 B/s (0.0%) |
1.0 B/s (0.0%) |
Out |
23.4 kB/s (1.9%) |
831.0 B/s (0.1%) |
931.0 B/s (0.1%) |
`Yearly' Graph (1 Day Average)
|
Max |
Average |
Current |
In |
35.2 kB/s (2.8%) |
144.0 B/s (0.0%) |
1.0 B/s (0.0%) |
Out |
31.9 kB/s (2.5%) |
1018.0 B/s (0.1%) |
769.0 B/s (0.1%) |
GREEN ### |
Incoming Traffic in Bytes per Second |
BLUE ### |
Outgoing Traffic in Bytes per Second |
