Run_0210

Run_0210 SEU Plots

Lone Bin SEUs Repeated Bin Number Total Number of Histograms
Count 769 0 3200
% of Total 24.0312 0 100
**Counts of lone bin and large width SEUs do not include overflow or histograms with repeated bins

SEU Bit Flips Bad DAC A Values vs. Relative Time SEUs + Overflow vs. DAC A Value

Lone Bin SEUs

meas_id dac_a_val dac_b_val timestamp channel histogram_mean histogram_rms histogram_range lone_bin_distance lone_bin_seu large_width_seu repeat_bin_number is_multimodal is_skewed is_near_transition histogram_link
2093 46080.0 19456.0 2023-10-28 10:16:42.214790 channel2 24551.069587 2.868894 400.0 [385.0] True True False False False False seu_2093_46080_channel2
3219 53248.0 12288.0 2023-10-28 10:39:52.903180 channel2 29223.744008 3.963843 965.0 [944.0] True True False True False False seu_3219_53248_channel2
358 34816.0 30720.0 2023-10-28 09:58:12.344759 channel4 16989.373526 1.302987 116.0 [10.0, 110.0] True True False False False False seu_358_34816_channel4
2602 49408.0 16128.0 2023-10-28 10:26:50.753052 channel4 26329.911237 3.006852 122.0 [108.0] True True False True False True seu_2602_49408_channel4
3770 56576.0 8960.0 2023-10-28 10:51:41.508283 channel4 30893.123707 3.955980 968.0 [948.0] True True False True False True seu_3770_56576_channel4
3262 53504.0 12032.0 2023-10-28 10:40:39.705408 channel7 15748.447111 1.335098 143.0 [137.0] True True False False False False seu_3262_53504_channel7

Repeated Bins

meas_id dac_a_val dac_b_val timestamp channel histogram_mean histogram_rms histogram_range lone_bin_distance lone_bin_seu large_width_seu repeat_bin_number is_multimodal is_skewed is_near_transition histogram_link
