Run_0232

Run_0232 SEU Plots

Lone Bin SEUs Repeated Bin Number Total Number of Histograms
Count 3035 2 61048
% of Total 4.9715 0.00327611 100
**Counts of lone bin and large width SEUs do not include overflow or histograms with repeated bins

SEU Bit Flips Bad DAC A Values vs. Relative Time SEUs + Overflow vs. DAC A Value

Lone Bin SEUs

meas_id dac_a_val dac_b_val timestamp channel histogram_mean histogram_rms histogram_range lone_bin_distance lone_bin_seu large_width_seu repeat_bin_number is_multimodal is_skewed is_near_transition histogram_link
41645 9728.0 55808.0 2023-10-29 02:24:17.362559 channel2 32711.323694 19.555600 32766.0 [32710.0, 47.0] True True False True False False seu_41645_9728_channel2
72125 9728.0 55808.0 2023-10-29 07:52:58.509219 channel2 32711.063861 19.589014 32766.0 [32710.0] True True False True False False seu_72125_9728_channel2
11174 9792.0 55744.0 2023-10-28 20:59:50.742975 channel2 32408.931023 3274.796601 32767.0 [32374.0, 280.0] True True False True True False seu_11174_9792_channel2
11183 9792.0 55744.0 2023-10-28 20:59:55.072185 channel2 32302.601832 3762.169519 32767.0 [32270.0] True True False True True False seu_11183_9792_channel2
41663 9792.0 55744.0 2023-10-29 02:24:26.175875 channel2 29147.273449 10247.275488 32767.0 [3558.0] True True False True True False seu_41663_9792_channel2
41672 9792.0 55744.0 2023-10-29 02:24:30.873004 channel2 29852.994944 9298.137247 32767.0 [2846.0, 2851.0] True True False True True False seu_41672_9792_channel2
56915 9792.0 55744.0 2023-10-29 05:09:13.263786 channel2 31136.601837 7080.064639 32767.0 [31098.0] True True False True True False seu_56915_9792_channel2
72143 9792.0 55744.0 2023-10-29 07:53:07.528115 channel2 29163.952398 10226.836502 32767.0 [29121.0] True True False True True False seu_72143_9792_channel2
26435 9856.0 55680.0 2023-10-28 23:40:41.067567 channel2 708.012567 4692.533921 32767.0 [32029.0] True True False True True False seu_26435_9856_channel2
56933 9856.0 55680.0 2023-10-29 05:09:22.910940 channel2 121.980000 1760.805992 32767.0 [33.0, 32627.0] True True False True True False seu_56933_9856_channel2
56942 9856.0 55680.0 2023-10-29 05:09:27.265961 channel2 146.583779 1979.253329 32767.0 [59.0, 32594.0] True True False True True False seu_56942_9856_channel2
72180 9856.0 55680.0 2023-10-29 07:53:38.353336 channel2 72.304572 1184.166320 32767.0 [17.0, 32678.0] True True False True True False seu_72180_9856_channel2
26227 9152.0 56384.0 2023-10-28 23:38:36.582555 channel4 32713.753445 774.104046 32767.0 [32696.0] True True False True False True seu_26227_9152_channel4
56725 9152.0 56384.0 2023-10-29 05:07:19.455677 channel4 32616.717647 1990.361585 32767.0 [32592.0, 78.0] True True False True True True seu_56725_9152_channel4
56734 9152.0 56384.0 2023-10-29 05:07:23.891458 channel4 32580.338178 2273.566224 32767.0 [114.0] True True False True True True seu_56734_9152_channel4
71953 9152.0 56384.0 2023-10-29 07:51:14.548279 channel4 32368.033027 3479.721217 32767.0 [32341.0, 32338.0] True True False True True True seu_71953_9152_channel4
10995 9216.0 56320.0 2023-10-28 20:57:33.627076 channel4 7436.945720 13714.379446 32767.0 [25294.0] True True False True True True seu_10995_9216_channel4
11004 9216.0 56320.0 2023-10-28 20:57:37.768172 channel4 10067.685627 15108.520582 32767.0 [22659.0] True True False True True True seu_11004_9216_channel4
71971 9216.0 56320.0 2023-10-29 07:51:23.812782 channel4 604.783897 4341.911978 32767.0 [32137.0, 32140.0] True True False True True True seu_71971_9216_channel4

Repeated Bins

meas_id dac_a_val dac_b_val timestamp channel histogram_mean histogram_rms histogram_range lone_bin_distance lone_bin_seu large_width_seu repeat_bin_number is_multimodal is_skewed is_near_transition histogram_link
50292 37632.0 27904.0 2023-10-29 03:57:32.203154 channel1 3503.051238 8155.857048 28733.0 None False True True False True False seu_50292_37632_channel1
37765 46400.0 19136.0 2023-10-29 01:42:17.506389 channel3 1068.941395 1787.978873 28734.0 None False True True False False False seu_37765_46400_channel3
