RTXC Quadros Single Stack LITE
The RTXC Quadros Single Stack LITE real-time operating system is a binary distribution of the RTXC/ss RTOS in a fixed configuration with limitations on the number of kernel objects. We have provided enough kernel support to handle the sample applications and the OpenTCP stack included with the M523xBCC and M5282LITE kits: 2 priority levels, 6 threads, 4 exceptions, 2 event sources, 3 counters, 3 alarms and 2 pipes. Note: The OpenTCP networking stack runs in polling mode and uses 1 alarm and 1 exception.

RTXC Quadros Single Stack LITE is available free of charge with no royalties or restrictions on how you use it. It is suited for small projects with limited deployment or for evaluation and proof-of-concept.

Full-featured RTXC Quadros RTOS products which include source code are available for purchase. Please visit the Quadros Systems web site for more information.

RTXC Quadros Technical Summary (PDF)

A technical overview of the RTXC Quadros RTOS products.

RTXC Quadros Kernel General Information and RTXCgen User's Guide (PDF)

This manual explains the inputs and outputs of the RTXC Quadros Kernel as a software component of an embedded application. The manual also contains instructions for using the RTXCgen System Generation Utility.

RTXC Quadros User's Guide Volume 1 (PDF)

Introduces the RTXC/ss component of the RTXC Quadros RTOS.

RTXC Quadros RTXC Quadros User's Guide Volume 2

Introduces the RTXC/ms component of the RTXC Quadros RTOS. This manual is not provided because the RTXC/ms component is not available as part of the M523xBCC and M5282LITE kits.

RTXC Quadros Kernel Services Reference, Volume 1 (PDF)

Levels, Threads, Exceptions, Pipes, Event Sources, Counters, and Alarms

RTXC Quadros Kernel Services Reference, Volume 2

Tasks, Semaphores, Queues, Mailboxes, Messages, Memory Partitions, and Mutexes
This manual is not provided because these kernel services are only available with the RTXC/ms component of the RTXC Quadros RTOS.
