Your first notebook

(10 minutes)

Select the Python 3 icon. The Launcher tab will be replaced with a new Python notebook. You’ll see your first empty cell, labeled In [1].

If you look at the notebook’s tab near the top of the page, you’ll see that the name of the notebook is Untitled. The first thing you should do when creating a new notebook is to give it a new name. Go to Jupyter’s File menu and select Rename Notebook… (near the middle of the menu). Pick any name you wish, such as pythontest.1

Figure 25: https://xkcd.com/1459/ by Randall Munroe

After you’ve renamed the notebook, look at your directory listing on the left. You’ll see the notebook file with the extension .ipynb.2

Copy-and-paste the following into that first cell.3

from ROOT import TH1D, TCanvas
my_canvas = TCanvas("mycanvas","canvas title",800,600)
example = TH1D("example","example histogram",100,-3,3)
example.FillRandom("gaus",10000)
exomple.Draw("E")
my_canvas.Draw()

Note

This code is in Python, but after going through The Basics you can probably figure out what most of these lines are supposed to do.

To “execute” the contents of a given cell, hit SHIFT-ENTER with your cursor in that cell. Do that now.

Oops! There’s an error. Fix the error in the cell and hit SHIFT-ENTER again.

Note

Assuming there have been no mistakes, you should see a histogram embedded in the web page.

There are also a couple of warning messages:

Warning in <TCanvas::Constructor>: Deleting canvas with same name: mycanvas
Warning in <TROOT::Append>: Replacing existing TH1: example (Potential memory leak).

Let’s think about what those messages mean. When you execute lines in a cell, your environment doesn’t “start fresh”; everything you defined before is still there. ROOT is warning you that the TCanvas and the histogram are being overridden.

In Python, you can usually ignore these warnings.

Click in the next cell and copy-and-paste this line, then hit SHIFT-ENTER:

exampleFit = example.Fit("gaus")

Note

This next cell recognizes the histogram object you defined in the previous cell. This gives you some idea of one feature of notebooks: You can fiddle with something in a given cell until it does what you want, then move on to the next phase of your task that depends on the previous cell.

Wait a moment… We just added a fit to the histogram, but the plot didn’t change. Maybe we have to plot it again.

Enter this line after the one you just pasted, or into a subsequent cell, and hit SHIFT-ENTER:

example.Draw()

Note

No new plot, and the plot above it still didn’t change. What’s wrong?

Nothing. Jupyter runs in a web browser, and browsers behave differently than X-Windows (the underlying graphics protocol of UNIX). You may have noticed that, unlike the ROOT plots in The Basics, the shape of the cursor doesn’t change as you move it over the plot, and right-clicking on it brings up a browser menu, not a ROOT one. If you right-click on the plot and select View Image, you’ll see that the plot is not a dynamic object, but a static .png file.4

How do we get a plot? You probably guessed the answer from what I had in the first cell. Paste the following line after that last Draw() command, or in a new cell:

my_canvas.Draw()

Finally, you see the histogram with the fit superimposed.

Note

Remember: ROOT plots everything in a canvas. In Jupyter, a TCanvas is not automatically drawn when its underlying plot updates. You have to explicitly draw the TCanvas yourself. That’s why the first example contains the lines:

my_canvas = TCanvas("mycanvas","canvas title",800,600)
# ... stuff ...
my_canvas.Draw()

I had to define the TCanvas that would be used as the “target” of any Draw commands, then Draw that TCanvas in order for the plot to be displayed.5

---

1

You don’t have to do this. But if you don’t, your home directory will soon be littered with notebooks named Untitled.ipynb, Untitled1.ipynb, Untitled2.ipynb, etc., and you won’t know what’s in any of them.

2

Here are more Jupyter hints. Of particular interest is the list of keyboard shortcuts; for some reason, you can’t see the list they mention in more advanced versions of JupyterLab, though the shortcuts are still there.

Some of those tips won’t work on the Nevis systems; e.g., you can’t install new extensions on the Nevis notebook server. The last tip, on different ways to share notebooks, will be helpful to those who work with folks who don’t use Jupyter.

3

You can type it in manually if you want, but (a) that’s a lot of typing, and (b) you have to make sure you get each character correct for the sake of this example.

4

“PNG” stands for Portable Network Graphics. It’s a standardized format for uncompressed images to be sent over the web. Jupyter uses that format instead of GIF because the GIF algorithm is patented.

5

Since we haven’t had to explicitly define our canvases before, I should mention: the canvas name and title are usually not important; the name only matters if you were to write the canvas to a file, and the canvas title is rarely displayed (as opposed to the histogram title, which appears at the top of the plot).

What matters is the size of the canvas. Here, I used 800 pixels wide and 600 pixels tall, which is the size of our old friend c1 that’s automatically defined if you don’t define a canvas yourself.

I could have defined the canvas using only defaults with

my_canvas = TCanvas()

but I thought that might be even more confusing to see for the first time.
